8-fibre AXXI, 50/OM3, SC-SC

From: excl. VAT

See variants

Pre-terminated break-out fiber optic cable with SC-SC connectors. The AXXI multimode cable is terminated in both ends when delivered, each fibre in the cable is distributed to the ends via a fan-out.

Variants
Description

Variant	Product Number	Length	Stock	Price
Variant: 8 Fiber Break-out cable AXXI 10m, SC-SC connectors, 50/OM3	Nummer: 7-B695743-7-010	Length 10 m	Stock:	Price:
Variant: 8 Fiber Break-out cable AXXI 20m, SC-SC connectors, 50/OM3	Nummer: 7-B695743-7-020	Length 20 m	Stock:	Price:
Variant: 8 Fiber Break-out cable AXXI 30m, SC-SC connectors, 50/OM3	Nummer: 7-B695743-7-030	Length 30 m	Stock:	Price:
Variant: 8 Fiber Break-out cable AXXI 50m, SC-SC connectors, 50/OM3	Nummer: 7-B695743-7-050	Length 50 m	Stock:	Price:

May be delivered with most connector types.
2-, 4-, 8-, 12– or 24-fibre cable with tight buffer.
Delivered in customer specified lengths.

Description

A manifold is attached at the end of the cable to fan out the fibres in a controlled way. Each fibre is individually protected by a 3.0 mm tube. For cables with more than 2 fibres the length of the 2 or 4 next fibres will increase with 5 cm (+0/-5 cm) for every 2. or 4. fibre.

Specifications

Cable type:
Tight buffer, AXXI, black Flame retardant, Zero halogen

Diameter cable:
9.6/9.6/9.9/10.8 mm 4/8/12/24-fibre AXXI

Tension strength cable:
800 N AXXI

Dimensions manifold (fan-out):
Ø 14 mm x 36 mm 2-fibre
Ø 20 mm x 75 mm 4-fibre
Ø 17 mm x 105 mm 8-fibre
Ø 35 mm x 165 mm 12/24-fibre

Diameter protection w/cable grip:
32 mm 2/4/8-fibre
52 mm 12/24-fibre

Diameter detachable protection:
49 mm (accessory 990443 - tube: Ø28 mm) 2/4/8-fibre
63 mm (accessory 990145 - tube: Ø42 mm) 12/24-fibre

Fibre type (acc. to EN 50173-1):
OM-1 (62.5/125) AXAI: grey
OM-2 (50/125) AXAI: orange
OM-3 (50/125) AXAI: turquoise

Insertion loss connectors:
< 0.5 dB @ 850/1300 nm < 0.2 dB typical

Operating temperature: -40°C to 60°C
