4-fibre Tactical cable, LC-LC, 50/125
Pre-terminated tactical cable for extreme conditions 4 fiber with LC-LC connectors.
|Variant: 4-fibre tactical cable, LC-LC, 50/125, 10 m||Nummer: L-904MIL50-L-010||Length 10 m||
|Variant: 4-fibre tactical cable, LC-LC, 50/125, 20 m||Nummer: L-904MIL50-L-020||Length 20 m||
|Variant: 4-fibre tactical cable, LC-LC, 50/125, 30 m||Nummer: L-904MIL50-L-030||Length 30 m||
|Variant: 4-fibre tactical cable, LC-LC, 50/125, 50 m||Nummer: L-904MIL50-L-050||Length 50 m||
Pre-terminated multi-mode 50/125 µm tactical cable for rough environments.
- For establishing temporary facilities in the field
- Defense, industry, offshore
- Military tactical cable for extreme use
- Fibre type: Multi-mode 50/125 µm
- Can be delivered in any length at all
- Up to 500 m on the reel
- Up to 2000 m on a different reel
A manifold is attached at the end of the cable to fan out the fibres in a controlled way. Each fibre is individually protected by a 3.0 mm tube. Length of free fibre will be as illustrated below. For cables with more than 2 fibres the length of the 2 next fibres will increase with 5 cm (+0/-5 cm) for every 2. fibre as shown.
The tactical cable may be delivered on a ruggedized cable reel. A wide selection of reels with stand are available, see separated data sheet for details. Dust caps attached to the cable may also be delivered.
As an option the connector side of the cable may be protected with a flexible tube. There are 2 types:
Protection cable-end (with or without pulling grip):
This is made from a flexible tube and is meant as transport/pulling protection before and during installation and is completely removed after use. Outside this tube an optional cable pulling grip may be placed if the cable shall be pulled through tubes.
Protection cable-end, detachable:
Here the protection may be taken of and put back on, it is therefore suited when the cable will be moved several times. The disadvantage may be that the protection can not be fully removed from the cable.
Military tactical cable, black Polyurethane
Military tactical cable LSZH, black Polyurethane, LSZH (Low Smoke Zero Halogen)
5.0/5.5/6.5 mm 2/4/8 fibre
Tension strength: 1800 N
Crush resistance: 440 N/cm
80/88 mm 2/4/8 fibre
Dimensions manifold (fan-out):
Ø 14 mm x 36 mm 2-fibre
Ø 20 mm x 75 mm 4-fibre
Ø 17 mm x 105 mm 8-fibre
Diameter protection w/cable grip:
32 mm 2/4/8 fibre
Diameter detachable protection:
49 mm (accessory 990443 - tube: Ø28 mm) 2/4/8-fibre
Operating temperature: -40°C to 60°C
FIBER (single mode)
OS-1 EN 50173-1
Insertion loss connectors:
< 0.5 dB @ 1310/1550 nm < 0.15 dB typical
Return loss connectors:
< -45 dB @ 1310/1550 nm for PC < -50 dB typical
< -60 dB @1310/1550 nm for APC < -65 dB typical
Classification, connectors: Class C2 (PC), class C1 (APC) IEC 61755-1
FIBER (multi mode)
OM-1 (62.5/125), OM-2 (50/125) EN 50173-1
Insertion loss connectors:
< 0.5 dB @ 850/1300 nm < 0.2 dB typical
