12-fibre AXAI, 9/OS2, LC/APC-LC/APC

Pre-terminated cable for mounting in FOSS panel type FP70. The cable is terminated in both ends when delivered.

• Connector: LC/APC according to IEC 61 754-20
• Fibre type: Single mode according to ITU-T G.657A1, EN 50173-1 OS2
• Quality: IEC 61755-1 class C1
• Cable: AXAI, tight buffer, fire retardant and halogen free, yellow
• Enables fast and secure mounting in FOSS panel FP70
• Combined in- and outdoor use
• Other lengths are quickly delivered from our production in Drammen. Please contact us

Specifications

Cable type:
Tight buffer, AXAI, several colours (see fibre type)               Flame retardant, Zero halogen
Tight buffer, AXXI, black                                                               Flame retardant, Zero halogen

Diameter cable:
5/6/6.5/8 mm                 4/8/12/24-fibre AXAI
9.6/9.6/9.9/10.8 mm      4/8/12/24-fibre AXXI

Tension strength cable:
440/680/900/1400 N               4/8/12/24-fibre AXAI
800 N                                          AXXI

Diameter w/cable grip:
34 mm                                       4-fibre
40 mm                                       8/12/24-fibre

Tension strength cable grip:
350 N

Fibre type:
ITU-T G.657.A1 (compatible with G.652.D)          AXAI
ITU-T G.652.D                                                             AXXI
OS-2                                                                            EN 50173-1

Insertion loss connectors:
< 0.5 dB @ 1310/1550 nm                    < 0.15 dB typical

Return loss connectors:
< -45 dB @ 1310/1550 nm for PC              < -50 dB typical
< -60 dB @1310/1550 nm for APC            < -65 dB typical

Classification, connectors:
Class C2 (PC), class C1 (APC)                  IEC 61755-1

Operating temperature:
-40°C to 60°C
