8-fibre AXXI, 50/OM3, LC-LC

From: excl. VAT
See variants

Pre-terminated break-out fiber optic cable with LC-LC connectors. The AXXI multimode cable is terminated in both ends when delivered, each fibre in the cable is distributed to the ends via a fan-out.

Variant Product Number Length Stock Price
Variant: 8 Fiber Break-out cable AXXI 10m, LC-LC connectors, 50/OM3 Nummer: L-B695743-L-010 Length 10 m
Variant: 8 Fiber Break-out cable AXXI 20m, LC-LC connectors, 50/OM3 Nummer: L-B695743-L-020 Length 20 m
Variant: 8 Fiber Break-out cable AXXI 30m, LC-LC connectors, 50/OM3 Nummer: L-B695743-L-030 Length 30 m
Variant: 8 Fiber Break-out cable AXXI 50m, LC-LC connectors, 50/OM3 Nummer: L-B695743-L-050 Length 50 m
  • May be delivered with most connector types.
  • 2-, 4-, 8-, 12– or 24-fibre cable with tight buffer.
  • Delivered in customer specified lengths.


A manifold is attached at the end of the cable to fan out the fibres in a controlled way. Each fibre is individually protected by a 3.0 mm tube.  For cables with more than 2 fibres the length of the 2 or 4 next fibres will increase with 5 cm (+0/-5 cm) for every 2. or 4. fibre.


Cable type:
Tight buffer, AXXI, black           Flame retardant, Zero halogen

Diameter cable:
9.6/9.6/9.9/10.8 mm                 4/8/12/24-fibre AXXI

Tension strength cable:
800 N            AXXI

Dimensions manifold (fan-out):
Ø 14 mm x 36 mm            2-fibre
Ø 20 mm x 75 mm           4-fibre
Ø 17 mm x 105 mm           8-fibre
Ø 35 mm x 165 mm         12/24-fibre

Diameter protection w/cable grip:
32 mm             2/4/8-fibre
52 mm             12/24-fibre

Diameter detachable protection:
49 mm (accessory 990443 - tube: Ø28 mm)             2/4/8-fibre
63 mm (accessory 990145 - tube: Ø42 mm)              12/24-fibre

Fibre type (acc. to EN 50173-1):
OM-1 (62.5/125)         AXAI: grey
OM-2 (50/125)           AXAI: orange
OM-3 (50/125)           AXAI: turquoise

Insertion loss connectors:
< 0.5 dB @ 850/1300 nm             < 0.2 dB typical

Operating temperature:  -40°C to 60°C
