4-fibre AICI, 62.5/OM1, ST-ST
Pre-terminated break-out cable AICI for use offshore and on ship 4 fiber with ST-ST connectors.
|Variant: 4-fibre AICI, 62.5/OM1, ST-ST, 10 m||Nummer: 1-B695424-1-010||Length 10 m||
|Variant: 4-fibre AICI, 62.5/OM1, ST-ST, 20 m||Nummer: 1-B695424-1-020||Length 20 m||
|Variant: 4-fibre AICI, 62.5/OM1, ST-ST, 30 m||Nummer: 1-B695424-1-030||Length 30 m||
|Variant: 4-fibre AICI, 62.5/OM1, ST-ST, 50 m||Nummer: 1-B695424-1-050||Length 50 m||
- Cable according to NEK 606 for use offshore and on ship.
- Single- or multi mode.
- May be delivered with most connector types.
- 4-fibre cable.
- Delivered in customer specified lengths.
A manifold is attached at the end of the cable to fan out the fibres in a controlled way. Each fibre is individually protected by a 3.0 mm tube.
Length of free fibre will be as illustrated below. For cables with more than 2 fibres the length of the 2 or 4 next fibres will increase with
5 cm (+0/-5 cm) for every 2. or 4. fibre as shown.
As an option the connector side of the cable may be protected with a flexible tube. There are 2 types:
Protection cable-end (with or without pulling grip):
This is made from a flexible tube and is meant as transport/pulling protection before and during installation and is completely removed after use. Outside this tube an optional cable pulling grip may be placed if the cable shall be pulled through tubes.
Protection cable-end, detachable:
Here the protection may be taken of and put back on again, it is therefore suited when the cable will be moved several times. The disadvantage may be that the protection attachment can not be removed from the cable.
Tight buffer, AICI, black, Flame retardant, Zero halogen NEK 606:2016: F104
Loose tube, QFCI, black, Flame retardant, Zero halogen NEK 606:2016: F101
8.2/9.4/10.3/12.0 mm 4/8/12/24-fibre AICI
13,5 mm QFCI
Tension strength at installation:
700/800/1200/1700 N 4/8/12/24-fibre AICI
1500 N QFCI
Dimensions manifold (fan-out):
Ø 14 mm x 36 mm 2-fibre
Ø 20 mm x 75 mm 4-fibre
Ø 35 mm x 165 mm 8/12/24-fibre
Diameter protection w/cable grip:
32 mm 2/4-fibre
52 mm 8/12/24-fibre
Diameter detachable protection:
49 mm (accessory 990443 - tube: Ø28 mm) 2/4/8-fibre
63 mm (accessory 990145 - tube: Ø42 mm) 12/24-fibre
Operating temperature: -40°C to 60°C
FIBER (single mode)
OS-2 EN 50173-1
Insertion loss connectors:
< 0.5 dB @ 1310/1550 nm < 0.15 dB typical
Return loss connectors:
< -45 dB @ 1310/1550 nm for PC < -50 dB typical
< -60 dB @1310/1550 nm for APC < -65 dB typical
Class C2 (PC), class C1 (APC) IEC 61755-1
OM-1 (62.5/125), OM-2 (50/125) or OM-3 (50/125) EN 50173-1
Insertion loss connectors:
< 0.5 dB @ 850/1300 nm < 0.2 dB typical
